Specifications
- Type: Outrunner
- Weight: 69.00g (2.43oz)
- Diameter: 28.10mm (1.11in)
- Length: 32.00mm (1.26in)
- Shaft Diameter: 3.00mm (0.12in)
- Maximum Amps: 12
Constants
- kV: 730
- Rm: 0.345
- Io: 0.45
Io Test Data
Dr Kiwi test results
| Volts | Amps | RPM |
|---|---|---|
| 7 | 0.35 | 5045 |
| 8 | 0.4 | 5770 |
| 10 | 0.45 | 7170 |
Test Data
Dr Kiwi test results
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
|---|---|---|---|---|---|---|---|---|---|
| GWS HD 9x5 | 1 | 6.9 | 2.35 | 16 | 4590 | 21.7 | 195 | 6.88 | 91% |
| GWS HD 9x5 | 1 | 7.9 | 2.9 | 22 | 5130 | 24.3 | 250 | 8.82 | 89% |
| GWS HD 9x5 | 1 | 8.9 | 3.4 | 30 | 5670 | 26.8 | 307 | 10.83 | 87% |
| GWS HD 9x5 | 1 | 9.9 | 4 | 39 | 6210 | 29.4 | 362 | 12.77 | 86% |
| GWS HD 9x5 | 1 | 10.9 | 4.65 | 50 | 6750 | 32.0 | 436 | 15.38 | 85% |
| GWS HD 3T 9x5 | 1 | 6.9 | 2.8 | 19 | 448 | 21.2 | 212 | 7.48 | 9% |
| GWS HD 3T 9x5 | 1 | 7.9 | 3.4 | 26 | 5020 | 23.8 | 272 | 9.59 | 87% |
| GWS HD 3T 9x5 | 1 | 8.9 | 4.1 | 36 | 5520 | 26.1 | 334 | 11.78 | 85% |
| GWS HD 3T 9x5 | 1 | 9.9 | 4.85 | 48 | 6040 | 28.6 | 408 | 14.39 | 84% |
| GWS HD 3T 9x5 | 1 | 10.8 | 5.55 | 59 | 6500 | 30.8 | 472 | 16.65 | 82% |
| GWS HD 3T 9x5 | 1 | 14 | 8 | 112 | 7960 | 37.7 | 713 | 25.15 | 78% |
| GWS HD 10x6 | 1 | 6.9 | 3.25 | 22 | 4350 | 24.7 | 257 | 9.07 | 86% |
| GWS HD 10x6 | 1 | 7.9 | 3.95 | 31 | 4860 | 27.6 | 326 | 11.50 | 84% |
| GWS HD 10x6 | 1 | 8.9 | 4.7 | 41 | 5370 | 30.5 | 398 | 14.04 | 83% |
| GWS HD 10x6 | 1 | 9.8 | 5.5 | 53 | 5850 | 33.2 | 470 | 16.58 | 82% |
| GWS HD 10x6 | 1 | 10.8 | 6.3 | 68 | 6300 | 35.8 | 546 | 19.26 | 80% |
| GWS HD 10x6 | 1 | 14 | 8.9 | 124 | 7740 | 44.0 | 794 | 28.01 | 76% |
| GWS HD 3T 10x6 | 1 | 6.9 | 4 | 27 | 4180 | 23.8 | 292 | 10.30 | 83% |
| GWS HD 3T 10x6 | 1 | 7.8 | 4.85 | 37 | 4680 | 26.6 | 364 | 12.84 | 82% |
| GWS HD 3T 10x6 | 1 | 8.8 | 5.7 | 50 | 5120 | 29.1 | 438 | 15.45 | 80% |
| GWS HD 3T 10x6 | 1 | 9.8 | 6.55 | 64 | 5540 | 31.5 | 516 | 18.20 | 77% |
| GWS HD 3T 10x6 | 1 | 10.7 | 7.5 | 80 | 5960 | 33.9 | 602 | 21.23 | 76% |
| GWS HD 3T 10x6 | 1 | 14 | 10.8 | 151 | 7200 | 40.9 | 909 | 32.06 | 70% |
| GWS HD 11x7 | 1 | 6.9 | 4.6 | 31 | 4080 | 27.0 | 356 | 12.56 | 81% |
| GWS HD 11x7 | 1 | 7.9 | 5.6 | 44 | 4500 | 29.8 | 436 | 15.38 | 78% |
| GWS HD 11x7 | 1 | 8.8 | 6.6 | 58 | 4920 | 32.6 | 522 | 18.41 | 77% |
| GWS HD 11x7 | 1 | 9.8 | 7.6 | 74 | 5340 | 35.4 | 612 | 21.59 | 75% |
| GWS HD 11x7 | 1 | 10.8 | 8.6 | 92 | 5700 | 37.8 | 706 | 24.90 | 72% |
| GWS HD 12x6 | 1 | 6.9 | 5.1 | 35 | 3930 | 22.3 | 387 | 13.65 | 78% |
| Propeller | Gear Ratio | Volts | Amps | Watts | RPM | Speed (mph) | Thrust (g) | Thrust (oz) | RPM as % of Kv*V |
| GWS HD 12x6 | 1 | 7.9 | 6.2 | 48 | 4350 | 24.7 | 488 | 17.21 | 75% |
| GWS HD 12x6 | 1 | 8.8 | 7.2 | 63 | 4740 | 26.9 | 580 | 20.46 | 74% |
| GWS HD 12x6 | 1 | 9.8 | 8.4 | 82 | 5130 | 29.1 | 682 | 24.06 | 72% |
| GWS HD 12x6 | 1 | 10.8 | 9.5 | 102 | 5460 | 31.0 | 770 | 27.16 | 69% |
| GWS HD 12x8 | 1 | 6.8 | 6.1 | 41 | 3690 | 28.0 | 421 | 14.85 | 74% |
| GWS HD 12x8 | 1 | 7.8 | 7.4 | 57 | 4050 | 30.7 | 512 | 18.06 | 71% |
| GWS HD 12x8 | 1 | 8.8 | 8.6 | 75 | 4380 | 33.2 | 615 | 21.69 | 68% |
| GWS HD 12x8 | 1 | 9.8 | 9.9 | 97 | 4740 | 35.9 | 706 | 24.90 | 66% |
| GWS HD 12x8 | 1 | 10.7 | 11.1 | 118 | 4980 | 37.7 | 783 | 27.62 | 64% |
| APC E 13x6.5 | 1 | 6.8 | 6.15 | 41 | 3690 | 22.7 | 450 | 15.87 | 74% |
| APC E 13x6.5 | 1 | 7.8 | 7.4 | 57 | 4050 | 24.9 | 552 | 19.47 | 71% |
| APC E 13x6.5 | 1 | 8.8 | 8.65 | 76 | 4380 | 27.0 | 654 | 23.07 | 68% |
| APC E 13x6.5 | 1 | 9.8 | 10 | 98 | 4740 | 29.2 | 760 | 26.81 | 66% |
| APC E 13x6.5 | 1 | 10.8 | 11.2 | 120 | 4980 | 30.7 | 850 | 29.98 | 63% |
| APC E 14x8.5 | 1 | 6.8 | 8.7 | 59 | 3150 | 25.4 | 470 | 16.58 | 63% |
| APC E 14x8.5 | 1 | 7.8 | 10.3 | 80 | 3420 | 27.5 | 570 | 20.11 | 60% |
| APC E 14x8.5 | 1 | 8.7 | 11.6 | 100 | 3690 | 29.7 | 670 | 23.63 | 58% |
| APC E 14x8.5 | 1 | 9.7 | 12.9 | 125 | 3930 | 31.6 | 775 | 27.34 | 56% |
| APC E 14x8.5 | 1 | 10.7 | 14.1 | 150 | 4110 | 33.1 | 875 | 30.86 | 53% |
